Ripmo
Highlights
- Size Specific Everything
- Flip Chip for 27.5”/29” mixed (MX) wheels
- Internal Frame Storage
- DW-Link
Description
BUILT TO RIP
The Ripmo isn’t just a bike; it’s a legend. With multiple “Best in Test” awards
and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail slaying machine. How do you improve on that? The Ripmo is loaded with new features internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. We’ve also expanded our sizing options and added size specific details—right down to the bottom bracket height.
| Frame Material: | Carbon |
| Wheel Size: | 29", Mixed: 29" front/27.5" rear |
| Rear Axle Standard: | 12x148mm Boost |
| Rear Shock: | Fox Float X, Factory Series, 2-Pos Adj. w/EVOL |
| Rear Shock Size: | 230mm x 60mm |
| Rear Suspension Travel: | 150mm |
| Headset: | Cane Creek 40 |
| Headset Standard: | ZS44mm/ZS56mm |
| Fork: | Fox Float 36, Factory Series, GripX, 160mm, 29” |
| Wheelset: | Blackbird Send Alloy, 32 Hole, S-M F: Send I 29” R: Send II 27.5”, XM-XL F: Send I 29” R: Send II 29” |
| Front Tire: | Maxxis DHF, 29”x 2.5”, Exo+ |
| Rear Tire: | S-M: Maxxis DHR2, 27.5” x 2.5”, Exo+ XM-XL: Maxxis DHR2, 29” x 2.5”, Exo+ |
| Crankset: | SRAM X0, Eagle Transmission, DUB, SM-MD: 165mm, XM-XL: 170mm |
| Bottom Bracket: | SRAM DUB BSA |
| Chain: | SRAM X0, Eagle Transmission |
| Rear Derailleur: | SRAM X0, Eagle Transmission |
| Cassette: | SRAM X0, Eagle Transmission, 10-52T |
| Seatpost: | Bike Yoke Revive Dropper, S: 125mm, M: 160mm, XM: 185mm, L-XL: 213mm |
| Seat Post Diameter: | 34.9mm |
| Seat: | WTB Silverado, Ti, 142mm |
| Shifters: | SRAM X0, Eagle Transmission |
| Handlebar: | Blackbird HiFi, 35mm, 800mm |
| Stem: | Blackbird, 35mm, S-M: 35mm, XM-XL: 50mm |
| Grips: | Lizard Skin Charger Evo |
| Brakes: | SRAM Code RSC, 4-Piston |
| Intended Use: | AM/Enduro |
29" - 160mm FORK (575mm AXLE TO CROWN)
| Size | S | M | M | L | XL |
|---|---|---|---|---|---|
| Reach | 436 | 456 | 478 | 506 | 540 |
| Stack | 616 | 622 | 633 | 643 | 654 |
| Top Tube | 578 | 605 | 630 | 630 | 685 |
| Wheelbase | 1195 | 1219 | 1249 | 1286 | 1329 |
| Head Tube° | 64.5°° | 64.5°° | 64.5°° | 64.5°° | 64.5°° |
| Head Tube | 85 | 95 | 110 | 125 | 140 |
| Seat Tube° | 77°° | 76.5°° | 76.5°° | 77°° | 77.5°° |
| Seat Tube | 395 | 400 | 415 | 457 | 477 |
| BB Height | 338 | 341 | 344 | 349 | 350 |
| BB Drop | 36 | 33 | 30 | 27 | 24 |
| Standover | 693 | 734 | 757 | 772 | 784 |
| Chainstay | 432 | 432 | 436 | 438 | 440 |
Size Guide
| Size | S | M | XM | L | XL |
|---|---|---|---|---|---|
| Height | 152 - 168 | 165 - 175 | 173 - 183 | 180 - 191 | 188 - 201 |
